• Supports various types of energy storage batteries, such as lead - acid batteries and lithium – ion batteries.
• Supports single - phase parallel operation and three - phase pure sine - wave output in parallel units.
• The voltage level of 200 - 240Vac can be selected for single - unit or parallel systems.
• Supports two photovoltaic inputs and has the function of tracking the maximum power charging/carrying capacity of two MPPT simultaneously. The MPPT efficiency is up to 99.9%。
•It has two output modes of mains bypass and inverter output, and has the function of uninterrupted power supply.
• There are four charging modes: PV only, mains power first, PV first and mains power/pv hybrid charging.
• Supports periodic battery charging and discharging.
• The energy saving mode function of a single machine reduces the energy loss of no load. • It has many protection functions to protect the safety of photovoltaic panels, storage batteries, loads and controllers themselves.
•Capacitive intelligent touch screen, menu operation, parameter setting intuitive and convenient..
• Built - in WiFi interfaces, providing native cloud - platform access capabilities. It can automatically synchronize time after connection.
Product Parameters
| Production Model | HJ-IO4811S(E-4) |
| PV Input Date | |
| Max, Input Power | 14.5KW |
| MPPT Operating Voltage Range | 60-450V |
| Max.Short Circuit Current | 18A+18A |
| Number of MPPT Trackers | 1+1 |
| Battery Input Data | |
| Battery Voltage Range | 90-280V/170-280V |
| Max.Charge/Discharge Current | 230A/230A |
| Battery Type | Lead-acid,lithium batteries,vented lead-acid battery, user customization |
| AC Data | |
| Nominal Power | 11KW |
| Nominal Voltage | 220/230/240V |
| Nominal Frequency | 50Hz/60Hz |
| Max.Current | 65A |
| Power Factor | ~1(0.8 lead – 0.8 lag can be set) |
| Protection | |
| Protection | Input Under-voltage Protection，Output Short Circuit Protection，Fan Fault Protection，Input Overvoltage Protection |
| General Data | |
| Operating Temperature Range | -10℃-65℃（useabove45℃derated） |
| Cooling | Natural cooling |
| Relative Humidity | 5~95%(surface no condensation) |
| Display | LCD |
| Communication | RS485/CAN |
| Installation | Wall-mounted |
| Dimension (W*D*H) | 620*390*196(mm) |
| Weight | 18.5Kg |
| Certification | |
| Production Certification | IEC-62109 |
