Efficient Higher Revenue: 150% DCInput Oversizing;
Wide MPPT voltage range: 50V-550V;
Max.input current per string: 20A,Compatible with high power modules;
Intelligent Simple 0&M: Smart l-V Curve Diagnosis Function: locate PV string faults accurately and automatically detect faults;
Intelligent Fault Detection: Ac side voltage and current waveforms real-time recorded, fast fault location;
Support RS485/WiFi/4G: remote monitoring and operation via PC or mobile phones;
Reliable Worry Free:IP66 Protection Degree:support outdoor installation;
AFCl Function (Optional): when an arc-fault is detected the inverter immediately stops operation;
Product Parameters
| Production Model | HJ-IG4823S(E-19) | HJ-IG4853S(E-21) |
| PV Input Date | ||
| Max, Input Power | 3KW | 4.5KW |
| MPPT Operating Voltage Range | 50V – 550V | |
| Max.Short Circuit Current | 20A | |
| Number of MPPT Trackers | 1 | |
| AC Data | ||
| Nominal Power | 2KW | 3KW |
| Nominal Voltage | 220/230/240V | |
| Nominal Frequency | 50HZ/60HZ | |
| Max.Current | 10A | 15A |
| Power Factor | >0.99 ( 0.8 leading ~ 0.8 lagging ) | |
| Protection | ||
| Protection | DC Reverse Polarity Protection Anti-islanding Protection AC Short Circuit Protection Residual Curent Monitoring Unit Insulation Resistance Monitoring Ground Fault Monitoring Grid Monitoring Py String Monitoring Surge Protection |
|
| General Data | ||
| Operating Temperature Range | -30° C ~ +60° C | |
| Cooling | Natural | |
| Relative Humidity | 0 ~ 100% | |
| Display | LCD / LED+APP | |
| Communication | RS485/WiFi/4G | |
| Installation | wall-mounted | |
| Protection Degree | IP66 | |
| Dimension (W*D*H) | 270 x 250 x 130 mm | |
| Weight | 6Kg | |
| Certification | ||
| Production Certification | IEC/EN 62109-1/2, IEC/EN 61000-6-1/3, EN50549, IEC61727/IEC62116 | |
