High Energy Density and Long Lifespan: Uses LFP 3.2V / 587Ah cells with high energy density and long cycle life, supporting high-frequency charge and discharge, reducing total lifecycle costs;
Efficient Liquid Cooling System: Liquid cooling technology precisely controls the battery temperature, improving system efficiency and safety, and ensuring stable operation in high or low-temperature environments;
Low Noise Operation: Noise level of <65 dB (at 1 meter from the system), suitable for environments with strict noise requirements;
Product Parameters
| Model | HJ-G1725-6250L |
| Cell Type | LFP 3.2V / 587Ah |
| Energy Rating | 6.25 MWh |
| Combined Configurations | 8P416S |
| Voltage Range | DC 1164.8V–1497.6V |
| Dimensions (L × W × H) | 6058 × 2438 × 2896 mm |
| Weight | ≈43 T |
| Ingress Protection Grade | IP55 |
| Fire Fighting Metdods | Container-level fire fighting system, including a gas detection device, fire alarm system, and FK-5-1-12 fire suppression system witd a pipe network. |
| Maximum Operating Altitude | 3000 m (>2000 m derating) |
| Operating Temperature Range | -30°C to 55°C (>45°C derating) |
| Cooling Metdod | Liquid Cooling |
| Communication Protocol | Modbus TCP/RTU, IEC 60870-5-104, CAN |
| Rated Output Power | 1725 kW |
| Rated Output Current | 1151 A |
| Total Harmonic Current Distortion (THDi) | <3% |
| Rated Grid Frequency | 50/60 Hz |
| Product Standards | IEC 62477-1, IEC 62619, IEC 63056, EU 2023/1542 |
| Safety Certifications | UN38.3, MSDS |
| EMC Certifications | EN IEC 61000-6-1/2/3/4 |
| Grid Connection Standards | EN 50549-1, EN 50549-2 |
Video
Document Download
-
2026-07-136.25MWhEnergy Storage Container System Download
