Efficient: 30 inputs,{>} 150% DC/AC ratio;
Each MPPT maximum current 80A, compatible with 182 and 210 series bifacial modules;
Patented heat transfer technology, continuous output increase of 5% at high temperature;
Safe: IP66, C5-M Anti-Corrosion level;
Intelligent string break, remote release for DC switch，active safety;
Support intelligent AC/DC terminal temperature detection;
Smart:Intelligent string monitoring, smart l-V curve scan;
Each MPPT online insulation fault detection facilitates rapid fault identification;
Low temperature antifreeze,reverse dust removal indoor dehumidification;
Economic:Inverter with 20ms fast reactive power response, can replace SVGt;
Support 400mm’aluminum wire connection, savingAC cable costt;
Support PLC communication,saving communication cables and construction cost;
Product Parameters
| Production Model | HJ-IG48603T(E-30) | HJ-IG48703T(E-31) |
| PV Input Date | ||
| Max, Input Power | 96KW | 112KW |
| MPPT Operating Voltage Range | 200V ~ 1000V | |
| Max.Short Circuit Current | 39A | |
| Number of MPPT Trackers | 3 | |
| AC Data | ||
| Nominal Power | 60kW | 70KW |
| Nominal Voltage | 230V / 400V | 277V / 480V |
| Nominal Frequency | 50Hz / 60Hz | |
| Max.Current | 95.6A | 92.6A |
| Power Factor | >0.99 ( 0.8 leading ~ 0.8 lagging ) | |
| Protection | ||
| Protection | Anti-islanding Protection AC Short Circuit Protection Residual Curent Monitoring Unit Insulation Resistance Monitoring Ground Fault Monitoring Grid Monitoring Py String Monitoring Surge Protection |
|
| General Data | ||
| Operating Temperature Range | -30° C ~ +60° C | |
| Cooling | Smart Cooling | |
| Relative Humidity | 0 ~ 100% | |
| Display | LCD / LED+APP | |
| Communication | RS485/WiFi / GPRS / Ethernet | |
| Installation | wall-mounted | |
| Protection Degree | IP66 | |
| Dimension (W*D*H) | 650 x 450 x 260 mm | |
| Weight | 50kg | |
| Certification | ||
| Production Certification | IEC/EN 62109-1/2, IEC/EN 61000-6-1/3, EN50549, IEC61727/IEC62116,UNE217001, UNE217002, NC RfG, NRS097-2-1, NB/T 32004, BIS | |
