Cost-Effective: Designed for a Cost-Effective Solution
Rounded Corner Design, Elegant Appearance
Adaptable to Different Scenarios: Multiple parameters can be adjusted according to user needs to suit various occasions
Power Below 3KW Does Not Support Battery-Only Mode
Supports Lithium Battery Communication
External Wi-Fi, Automatic Generator Start Dry Contact Function
Real-Time Display of Actual Load Power, Significantly Enhances User Experience
Pure Sine Wave Output, Suitable for Various Loads
Output Short Circuit Protection Function
Product Parameters
| Product Model | HJ-HIO4883S-L (H-23) | HJ-HIO4814S-Pro-L (H-24) | |
| Input | Rated Voltage | 220/230/240VAC | 220/230/240VAC |
| Voltage Range | 90-280VAC±3V (Normal Mode) 170-280VAC±3V (UPS Mode) | 90-280VAC±3V (Normal Mode) 170-280VAC±3V (UPS Mode) | |
| Frequency Range | 50Hz/60Hz (Auto-adaptive) | 50Hz/60Hz (Auto-adaptive) | |
| Output | Rated Power | 11000W | 11000W |
| Output Voltage (AC) | 220/230/240VAC±5% | 220/230/240VAC±5% | |
| Output Frequency | 50/60Hz±0.1% | 50/60Hz±0.1% | |
| Waveform | Sine Wave | Sine Wave | |
| Transfer Time (Optional) | Computer Equipment: 10ms, Household Appliances: 20ms | Computer Equipment: 10ms, Household Appliances: 20ms | |
| Peak Power | 22000W | 22000W | |
| Overload | Battery Mode: 11s@105%~150% Load; 2s@150%~200% Load; 400ms@>200% Load | Battery Mode: 11s@105%~150% Load; 2s@150%~200% Load; 400ms@>200% Load | |
| Battery | Rated Voltage | 48VDC | 48VDC |
| Constant Voltage Charging Voltage (Optional) | 56.4VDC | 56.4VDC | |
| Float Charging Voltage (Optional) | 54VDC | 54VDC | |
| Charger | PV Charging Method | Dual MPPT | Dual MPPT |
| Max PV Input Power | 2×5500W | 2×5500W | |
| MPPT Tracking Range | 90-500VDC | 90-500VDC | |
| Optimal Vmp Working Range | 300~400VDC | 300~400VDC | |
| Max PV Input Voltage | 500VDC | 500VDC | |
| Max PV Input Current | 18A/18A | 18A/18A | |
| Max PV Charging Current | 150A | 150A | |
| Max AC Charging Current | 150A | 150A | |
| Max Charging Current | 150A | 150A | |
| Display | LCD Display | Operation Mode / Load / Input / Output, etc. | Operation Mode / Load / Input / Output, etc. |
| Communication Ports | RS232 | Baud Rate 2400 | Baud Rate 2400 |
| Expansion and Configuration Ports | Lithium Battery BMS Communication Card, Wi-Fi Card, Dry Contact Card, etc. | Lithium Battery BMS Communication Card, Wi-Fi Card, Dry Contact Card, etc. | |
| Parallel Interface | Parallel Function | Parallel Function | |
| Environmental Parameters | Operating Temperature | -10℃~+50℃ | -10℃~+50℃ |
| Operating Humidity | 20%~95% (Non-condensing) | 20%~95% (Non-condensing) | |
| Noise | <45dB | <45dB | |
| Grid Connection | Output Voltage | 220/230/240VAC | 220/230/240VAC |
| Grid Voltage Range | 195-253VAC | 195-253VAC | |
| Grid Frequency Range | 49-51±1Hz / 59-61±1Hz | 49-51±1Hz / 59-61±1Hz | |
| Rated Output Current | 47.8A | 47.8A | |
| Power Factor Range | >0.99 | >0.99 | |
| Max Conversion Efficiency (DC/AC) | 98% | 98% | |
| Physical Parameters | Depth×Width×Height (mm) | 601×360×163.5mm | 601×360×163.5mm |
| Standards and Certifications | EN-IEC60335-1, EN-IEC60335-2-29, IEC62109-1 | EN-IEC60335-1, EN-IEC60335-2-29, IEC62109-1 | |
