• Supports various types of energy storage batteries, such as lead - acid batteries and lithium – ion batteries.
• Supports single - phase parallel operation and three - phase pure sine - wave output in parallel units.
• The voltage level of 200 - 240Vac can be selected for single - unit or parallel systems.
• Supports two photovoltaic inputs and has the function of tracking the maximum power charging/carrying capacity of two MPPT simultaneously. The MPPT efficiency is up to 99.9%。
•It has two output modes of mains bypass and inverter output, and has the function of uninterrupted power supply.
• There are four charging modes: PV only, mains power first, PV first and mains power/pv hybrid charging.
• Supports periodic battery charging and discharging.
• The energy saving mode function of a single machine reduces the energy loss of no load. • It has many protection functions to protect the safety of photovoltaic panels, storage batteries, loads and controllers themselves.
•Capacitive intelligent touch screen, menu operation, parameter setting intuitive and convenient..
• Built - in WiFi interfaces, providing native cloud - platform access capabilities. It can automatically synchronize time after connection.
Product Parameters
| Production Model | HJ-IO48123S(E-5) |
| PV Input Date | |
| Max, Input Power | 9000W+9000W |
| MPPT Operating Voltage Range | 125-425V |
| Max.Short Circuit Current | 22A+22A |
| Number of MPPT Trackers | 2 |
| Battery Input Data | |
| Battery Voltage Range | 40-60V |
| Max.Charge/Discharge Current | 200A |
| Battery Type | Li-ion/Lead-acid |
| AC Data | |
| Nominal Power | 12000W |
| Nominal Voltage | 230V |
| Nominal Frequency | 50/60Hz |
| Max.Current | 200A |
| Power Factor | 0.8（leading）~0.8（lagging） |
| Protection | |
| Protection | PV Reverse Polarity Protection，Overcurrent Protection，Surge Protection |
| General Data | |
| Operating Temperature Range | -10~55℃ |
| Cooling | Intelligent air cooling |
| Relative Humidity | 5% to 95% relative humidity (non-condensing) |
| Display | LCD,WIFI+APP |
| Communication | CAN/GPRS/WIFI/Bluetooth/4G/LAN |
| Installation | wall-mounted |
| Dimension (W*D*H) | 450*620*142mm |
| Weight | 23.5kg |
| Certification | |
| Production Certification | IEC62109-1/2,EN61326-1:2013 |
