Efficient Higher Revenue: 150% DCInput Oversizing;
Wide MPPT voltage range: 50V-550V;
Max.input current per string: 20A,Compatible with high power modules;
Intelligent Simple 0&M: Smart l-V Curve Diagnosis Function: locate PV string faults accurately and automatically detect faults;
Intelligent Fault Detection: Ac side voltage and current waveforms real-time recorded, fast fault location;
Support RS485/WiFi/4G: remote monitoring and operation via PC or mobile phones;
Reliable Worry Free:IP66 Protection Degree:support outdoor installation;
AFCl Function (Optional): when an arc-fault is detected the inverter immediately stops operation;
Product Parameters
| Production Model | HJ-IG4833S(E-20) |
| PV Input Date | |
| Max, Input Power | 7KW |
| MPPT Operating Voltage Range | 200-500V |
| Max.Short Circuit Current | 20A |
| Number of MPPT Trackers | 1 |
| AC Data | |
| Nominal Power | 3.6KW |
| Nominal Voltage | 230V |
| Nominal Frequency | 50HZ/60HZ |
| Max.Current | 16A |
| Power Factor | 0.8 leading …0.8 lagging |
| Protection | |
| Protection | DC Reverse Polarity Protection Insulation Resistance Detection Surge Protection Over-temperature Protection Residual Current Protection Anti-islanding Protection AC Short-circuit Protection AC Over-voltage Protection |
| General Data | |
| Operating Temperature Range | -30~60 |
| Cooling | Natural Convection |
| Relative Humidity | 0~100 |
| Display | OLED |
| Communication | RS485/WiFi/GPRS/LAN |
| Installation | Wall-mounted |
| Protection Degree | IP66 |
| Dimension (W*D*H) | 327*297*114mm |
| Weight | 6.5kg |
| Certification | |
| Production Certification | IEC, CE |
