Efficient: 30 inputs,{>} 150% DC/AC ratio;
Each MPPT maximum current 80A, compatible with 182 and 210 series bifacial modules;
Patented heat transfer technology, continuous output increase of 5% at high temperature;
Safe: IP66, C5-M Anti-Corrosion level;
Intelligent string break, remote release for DC switch，active safety;
Support intelligent AC/DC terminal temperature detection;
Smart:Intelligent string monitoring, smart l-V curve scan;
Each MPPT online insulation fault detection facilitates rapid fault identification;
Low temperature antifreeze,reverse dust removal indoor dehumidification;
Economic:Inverter with 20ms fast reactive power response, can replace SVGt;
Support 400mm’aluminum wire connection, savingAC cable costt;
Support PLC communication,saving communication cables and construction cost;
Product Parameters
| Production Model | HJ-IG48354T(E-35) |
| PV Input Date | |
| Max, Input Power | 720KW |
| MPPT Operating Voltage Range | 480 – 1500 V |
| Max.Short Circuit Current | 6 × 80 A |
| Number of MPPT Trackers | 6 |
| AC Data | |
| Nominal Power | 320KW |
| Nominal Voltage | 3/PE, 800 V |
| Nominal Frequency | 50 Hz |
| Max.Current | 254 A |
| Power Factor | > 0.99 (0.8 leading – 0.8 lagging) |
| Protection | |
| Protection | DC reverse-polarity protection Short circuit protection Output over current protection Surge protection Grid monitoring Anti-islanding protection Temperature protection Strings monitoring I’ Curve scanning Night time SvG function Integrated PiD recovery Integrated DC switch |
| General Data | |
| Operating Temperature Range | -30 ~ +60℃ |
| Cooling | Intelligent fan-cooling |
| Relative Humidity | 0 ~ 100% |
| Display | LED indicator & Bluetooth + APP |
| Communication | RS485 / PLC |
| Installation | wall-mounted |
| Protection Degree | IP66 |
| Dimension (W*D*H) | 1098 × 813 × 378.5 mm |
| Weight | 117 kg |
| Certification | |
| Production Certification | IEC62109-1/-2, EN61000-6-2/-4 |
