Multiple Energy Sources Access: Supports the integration of various green power sources such as photovoltaic, wind, and diesel generators;
Intelligent System Management: Optimized energy saving and monitoring management; temperature control fans automatically adjust wind speed, low power consumption, and support RS485 serial communication for data upload;
Dual-layer Insulation Structure: Low overall thermal conductivity (thermal conductivity coefficient 0.024W/(m·K));
Easy to Transport and Install: The product shell is made of aluminum alloy, lightweight and easy to handle manually; prefabricated at the factory, and the cabinet can be lifted as a whole;
Strong Corrosion Resistance: The outer layer of the cabinet is made of FRP material with strong corrosion resistance, suitable for coastal environments;
Product Parameters
| Model | HJ-Z06-10O | HJ-Z12-20O | HJ-Z18-30O | HJ-Z24-40O |
| Power | 6KW (Maximum 9KW) | 12KW (Maximum 24KW) | 18KW (Maximum 36KW) | 24KW (Maximum 48KW) |
| Maximum Energy Storage Capacity | 10KWh | 20KWh | 30KWh | 40KWh |
| Energy Input/Output | Grid Power / Photovoltaic / Energy Storage | |||
| Operating Environment | Outdoor | Outdoor (Dual Chamber) | ||
| Installation Method | Floor-Mounted | |||
| Dimensions | 1200mm*700mm*700mm | 1600mm*700mm*700mm | 2000mm*750mm*750mm | 2000mm*1550mm*800mm |
