• Supports various types of energy storage batteries, such as lead - acid batteries and lithium - ion batteries.
• Supports single-phase and split-phase pure sine wave output.
• Supports voltage adjustment for each phase within the range of 100 to 120V.
• Supports single-channel photovoltaic input and features the function of simultaneously tracking MPPT maximum power charging/carrying capacity for one channel. The MPPT efficiency reaches up to 99.9%, and the maximum current per channel is 27A.
• Features two output modes: mains bypass and inverter output, and has an uninterruptible power supply function.
• Offers four charging modes: photovoltaic only, mains - priority, photovoltaic - priority, and mains/photovoltaic hybrid charging.
• Supports timed battery charging and timed battery discharging.
• The single - unit energy - saving mode function reduces no - load energy loss.
• Equipped with multiple protection functions to comprehensively protect the safety of photovoltaic panels, batteries, loads, and the controller itself.
• Features a capacitive intelligent touch - screen, menu - based operation, and intuitive and convenient parameter setting.
• Supports 256 event records and 1024 - day historical data storage.
• Built - in Bluetooth and WiFi interfaces, providing native cloud - platform access capabilities. It can automatically synchronize time after connect
Product Parameters
| Production Model | HJ-IO4853P(E-8) | HJ-IO4863P(E-9) | HJ-IO4883P(E-10) |
| PV Input Date | |||
| Max, Input Power | 7.5KW | 9KW | 7.5KW+7.5KW |
| MPPT Operating Voltage Range | 125-425V | ||
| Max.Short Circuit Current | 27A | 22A+22A | |
| Number of MPPT Trackers | 1 | 2 | |
| Battery Input Data | |||
| Battery Voltage Range | 40-60V | ||
| Max.Charge/Discharge Current | 120A | 200A | |
| Battery Type | Li-ion/Lead-acid / User – defined | Li-ion/Lead-acid | |
| AC Data | |||
| Nominal Power | 5KW | 6KW | 8KW |
| Nominal Voltage | 240V | 230V | |
| Nominal Frequency | 50/60Hz | ||
| Max.Current | 120A | 200A | |
| Power Factor | 0.8（leading）~0.8（lagging） | ||
| Protection | |||
| Protection | PV Reverse Polarity Protection，Overcurrent Protection，Surge Protection | ||
| General Data | |||
| Operating Temperature Range | -10~55℃ | ||
| Cooling | Intelligent air cooling | ||
| Relative Humidity | 5% to 95% relative humidity (non-condensing) | ||
| Display | LCD,WIFI+APP | ||
| Communication | RS485/CAN//Wifi/Bluetooth/4G | CAN/GPRS/WIFI/Bluetooth/4G/LAN | |
| Installation | wall-mounted | ||
| Dimension (W*D*H) | 472*422*130mm | 472*412*130mm | 450*620*142mm |
| Weight | 17.2kg | 16Kg | 23.5Kg |
| Certification | |||
| Production Certification | UL1741 / FCC | IEC62109-1/IEC62109-2 ,EN61326-1:2013 | |
