Higher Power Output: Generates more electricity, improving the overall system efficiency to meet the growing energy demands in various application scenarios;
Lower Levelized Cost of Electricity (LCOE): Reduces electricity costs by lowering production and maintenance expenses;
Less Shading and Lower Resistance Loss: Optimized design minimizes the impact of shading on power generation and reduces internal resistance, ensuring efficient energy transmission and better overall performance;
Better Mechanical Load Resistance: A robust component structure that can withstand various environmental stresses, such as wind and snow loads, extending the lifespan and reliability of the photovoltaic system;
Product Parameters
| Electrical Characteristics | |||||||
| Model | HJ-SM450-12M | ||||||
| Test Conditions | STC | ||||||
| Maximum Power (Pmax/W) | 425 | 430 | 435 | 440 | 445 | 450 | 455 |
| Open-Circuit Voltage (Voc/V) | 48.3 | 48.5 | 48.7 | 48.9 | 49.1 | 49.3 | 49.5 |
| Short-Circuit Current (Isc/A) | 11.23 | 11.31 | 11.39 | 11.46 | 11.53 | 11.6 | 11.66 |
| Maximum Power Voltage (Vmp/V) | 40.5 | 40.7 | 40.9 | 41.1 | 41.3 | 41.5 | 41.7 |
| Maximum Power Current (Imp/A) | 10.5 | 10.57 | 10.64 | 10.71 | 10.78 | 10.85 | 10.92 |
| Module Efficiency (%) | 19.6 | 19.8 | 20 | 20.2 | 20.5 | 20.7 | 20.9 |
| STC (Standard Test Conditions): Irradiance 1000W/m², Cell Temperature 25°C, Spectrum AM1.5. | |||||||
