Parallel/Off-Grid Dual Mode, Pure Sine Wave Output: Supports operation without batteries and automatic lithium battery activation, adapting to various power usage scenarios;
High Power MPPT and Dual PV Inputs: Equipped with a 160A solar charger, supports a wider PV voltage range (90~500VDC), and offers higher energy generation efficiency;
Intelligent Connectivity and Convenient Operation: Supports WiFi & GPRS remote monitoring, compatible with iOS and Android systems, and features electronic touch buttons with one-touch recovery functionality;
Intelligent Charging and Battery Protection: Optimized charging strategy effectively extends battery life;
Stable and Durable, Adapts to Harsh Environments: Built-in dust protection kit, dual output channels ensure long-term stable system operation;
Product Parameters
| Product Model | HJ-HIO4883S (H-27) |
|---|---|
| Phase | Single-Phase |
| Max Solar Input Power | 5400W+5400W |
| Rated Output Power | 8200W/8200VA |
| Max Solar Charging Current | 160A |
| AC Start Voltage/Auto Restart Voltage | 120-140VAC/180VAC |
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC |
| Frequency Range | 59~61+1HZ |
| Max AC Input Current | 48.2A |
| Rated DC Voltage/Max DC Voltage | 360/500VDC |
| MPPT Voltage Range | 90-450VDC |
| Max Input Current | 2/18A |
| Rated Output Voltage | 220/230/240VAC |
| Output Waveform | Pure Sine Wave |
| Efficiency (DC to AC) | 90% |
| Rated DC Voltage | 48VDC |
| Max Solar Charging Current | 160A |
| Max AC Charging Current | 140A |
| Max Solar + AC Charging Current | 160A |
| Rated DC Voltage/Max DC Voltage | 360/500VDC |
| Startup Voltage/Initial Supply Voltage | 90VDC/120VDC |
| MPPT Voltage Range | 90-450VDC |
| Max Input Current | 2/18A |
| Rated Output Voltage | 220/230/240VAC |
| Operating Temperature | -10℃~50℃ |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Output Voltage Range | 195-253VAC |
| Rated Output Current | 35.6A |
| AC Startup Voltage/Auto Restart Voltage | 90-280VAC or 170-280VAC |
| Acceptable Input Voltage Range | 48.2A |
| Max AC Input Current | 140A |
| Dimensions (L×W×H, mm) | 530*390*130 |
| Package Dimensions (L×W×H, mm) | 618*463*205 |
| Net Weight (kg) | 14.2 |
| Gross Weight (kg) | 15.7 |
| Communication Ports | RS232/RS485/WIFI/GPRS/LITHIUM BATTERY |
| Safety Standards Compliance | CE |
