Safe and Reliable: Uses high-quality lithium iron phosphate (LiFePO₄) battery cells, certified by international safety standards such as MSDS, UN38.3, ROHS, IEC62619, UL, with a cycle life exceeding 6,000 cycles;
Intelligent Battery Management System (BMS): Equipped with an integrated intelligent BMS that monitors the voltage, current, and temperature of individual batteries. It includes overcharge, overdischarge, overcurrent, temperature protection, and active balancing functions to ensure battery consistency and extend its lifespan;
Supports Multiple Module Parallel Connections: Supports up to 16 battery modules in parallel, offering strong expandability and flexibility to adapt to different power and capacity requirements;
Efficient and Energy-Saving Design: Features a low-power architecture with no relays, achieving standby power consumption as low as milliwatts, improving overall energy efficiency;
Product Parameters
| Product Model | HJ-HBL48101W (B-5) |
| Rated Voltage | 51.2V |
| Rated Capacity | 100Ah |
| Rated Energy | 5.12kWh |
| Output Voltage Range | 43.2V ~ 58.4V |
| Charging Voltage | 57.6 ~ 58.4V |
| Cutoff Voltage | 43.2V |
| Max Charging Current | 100A |
| Recommended Charging Current | 50A |
| Max Discharging Current | 100A |
| Efficiency | 98% |
| Dimensions (H×W×D, mm) | 550×370×185 |
| Carton Dimensions (H×W×D, mm) | 630×460×235 |
| Net Weight (kg) | 45 |
| Gross Weight (kg) | 47 |
| Humidity | 5% ~ 95% Relative Humidity |
| Charging Temperature | -20℃ ~ 65℃ |
| Discharging Temperature | -20℃ ~ 60℃ |
| Storage Temperature | -10℃ ~ 50℃ |
| Cycle Life | >6000 cycles (0.2C, @25℃, 80% DOD) |
| Design Life | >10 years |
| Operating Mode | Touchscreen |
