High-Quality LiFePO₄ Cathode Material: Utilizes a high-safety LiFePO₄ chemical system, with the battery offering over 6,000 cycles of lifespan, making it suitable for long-term stable operation;
Intelligent BMS Control System: Supports full control of charging, discharging, float charging, and sleep modes, with multi-level voltage, current, and temperature protection functions, ensuring optimized system operation;
Comprehensive Monitoring Capability: Continuously tracks voltage, current, temperature, capacity, and operational status, enhancing system intelligence and reliability;
Built-in Intelligent Balancing Module: Maintains consistency of battery cells during long-term use, thereby extending the overall lifespan of the battery pack;
Advanced Thermal Management: Equipped with an intelligent temperature control unit, supporting a wide temperature range operation, adaptable to various environments;
Product Parameters
| Product Model | HJ-HBL48101W (B-22) |
| Battery Chemistry | LiFePO4 |
| Max Continuous Discharge Current | 100A |
| Usable Capacity | 5120Wh |
| Rated Voltage | 51.2V |
| Voltage Range | 40-58.4V |
| Max Charging Voltage | 58.4V |
| Recommended Charging Voltage | 58.4V |
| Recommended Charging Current | 50A |
| Cycle Life (Standard Charging/Discharging at Room Temperature) | ≥6000 cycles |
| Communication | Standard RS485, CAN |
| Depth of Discharge (DOD) | ≥95% |
| Operating Temperature Range | Charging: 0℃～60℃; Discharging: -20℃～60℃; |
| Storage Temperature | 1 month: -20℃～45℃; 1 year: 0℃～35℃; |
| Weight (Net, for reference) | 42.5kg |
| Dimensions (L×W×H, mm) | 550×360×140 mm |
