High Power Output: N-type MBB half cut technology, improve energy density, bring higher power output. High Bifacial Factor, up to 25% extra power generation
High Durability: Passed TUV Salt & Ammonia corrosion test, and 2400Pa wind load, 5400Pa snow load test, higher reliability
Better Low Light Performance:Higher power generation compare with standard module in cloudy, foggy and low light condition
Low Power Degradation: First year power degradation <1.0%，year 2-30 power degradation <0.40% each year
Low Temperature coefcient:Passivated contact cell technology for higher power generation in operating
Better Anti-LID:O-type cells with boron-oxide-free composite LID to increase module power generation
Product Parameters
Electrical Data(STC)
| Maximum Power (Pmax/W) | 710 | 715 | 720 | 725 | 730 |
| Open Circuit Voltage (Voc/V) | 48.67 | 48.82 | 48.97 | 49.12 | 49.27 |
| Short Circuit Current (Isc/A) | 18.24 | 18.31 | 18.38 | 18.45 | 18.52 |
| Voltage at Maximum Power (Vmp/V) | 40.89 | 41.04 | 41.19 | 41.34 | 41.49 |
| Current at Maximum Power (Imp/A) | 17.37 | 17.43 | 17.48 | 17.54 | 17.60 |
| Module Efficiency (%) | 22.86 | 23.02 | 23.18 | 23.34 | 23.50 |
| Operating Temperatur | e -40° C~+85° C | ||||
| Maximum System Voltage | 1000/1500V | ||||
| STC (Standard Testing Conditions): lrradiance 1000W/m2, Cell Temperature 25℃ , AM1.5 | |||||
Electrical Data (NMOT)
| Maximum Power (Pmax/W) | 534 | 538 | 542 | 546 | 550 |
| Open Circuit Voltage (Voc/V) | 45.77 | 45.92 | 46.07 | 46.22 | 46.37 |
| Short Circuit Current (Isc/A) | 14.98 | 15.04 | 15.10 | 15.14 | 15.23 |
| Voltage at Maximum Power (Vmp/V) | 37.81 | 37.96 | 38.11 | 38.26 | 38.41 |
| Current at Maximum Power (Imp/A) | 14.13 | 14.18 | 14.23 | 14.28 | 14.32 |
| NMOT (Nominal Moudule Operating Temperature): lrradiance 800W/m2, Ambient Temperature 20℃ , AM1.5, Wind Speed 1m/s. | |||||
Bifacial Power Generation Parameters (backside gains)
| 5% | Maximum Power (Pmax/W) | 746 | 751 | 756 | 761 | 767 |
| Module Efficiency (%) | 24.00 | 24.17 | 24.34 | 24.51 | 24.68 | |
| 15% | Maximum Power (Pmax/W) | 817 | 822 | 828 | 834 | 840 |
| Module Efficiency (%) | 26.28 | 26.47 | 26.66 | 26.84 | 27.03 | |
| 25% | Maximum Power (Pmax/W) | 888 | 894 | 900 | 906 | 913 |
| Module Efficiency (%) | 28.57 | 28.77 | 28.97 | 29.17 | 29.38 |
Mechanical Data
| Cell Type | 210×105mm Mono |
| Cell Orientation | 132(6×22) |
| Module Dimensions | 2384×1303×33mm |
| Weight | 37.5kg |
| Front Glass | 2.0mm high transmittance, reinforced glass |
| Rear Glass | 2.0mm part of the structure is grid-like white ceramic glass |
| Frame Material | Anodized aluminum alloy |
| Junction Box | Protection class IP68 |
| Cable | 4.0 mm2 positive pole: 250mm negative pole: 300 mm wire length can be customized |
Temperature Coefficients
| Temperature Coefficient (Pm) | -0.290%/℃ |
| Temperature Coefficient (Voc) | -0.250%/℃ |
| Temperature Coefficient (Isc) | 0.045%/℃ |
| NMOT (Nominal Moudule Operating Temperature) | 41±3℃ |
Packaging
| Transportation methodsper pallet | Number of modules per cabinet | Number of modules |
| 40HQ container | 594 pcs | 33 pcs |
