Effective air conditioning refrigeration
Highly Efficient Three-Level Control System
Total Energy ranges from 112kWh to 261kWh
Outdoor Use Is Available
PCS /inverter wide range of options
Convenient screen operation
Product Parameters
| Model | HJ-G125-261L |
|---|---|
| DC Side Parameters | |
| Cell Type | LFP 3.2V/314Ah |
| Energy Rating | 261kWh |
| Combined Configurations | 1P260S |
| Voltage Range | 728-936V DC |
| Number Of Cycles | ≥6000 @25℃ |
| Depth of Discharge | 90%DOD |
| Communication Interface | Modbus TCP,Modbus RTU,CAN2.0 |
| Grid-connected output parameters | |
| Rated output power | 125kW |
| Rated grid voltage | 230/400V,3L+N+PE |
| Max current | 198A |
| Power factor | 0.99 |
| Rated grid Freq. | 50/60Hz |
| Total Harmonic Current Distortion | < 2%（rated power） |
| Off-grid output parameters | |
| Rated output power | 125kW |
| Rated Output voltage | 230V/400V |
| Rated grid Freq. | 50/60Hz |
| Max output current | 198A |
| Off-grid switching time | 20ms |
| Efficiency | |
| Maximum efficiency | 99.00% |
| System parameter | |
| Dimensions (H * D * W) | 1055*2300*1300 |
| Weights | ≈2.8T |
| Ingress Protection Grade | IP54 |
| Corrosion Resistance Class | C4 |
| Operating Temperature Range | charge：0℃~55℃(32 °F~131 °F)discharge：-20℃~55℃ (-4 °F~131 °F) |
| Operating humidity range | 5%～95%（No Condensing） |
| Cooling method | Liguid cooling |
| Fire Fighting Methods | Aerosol Suppression at Pack Level |
| Max. operating altitude | ≤2000 m |
| Communication Protocol | Modbus TCP,Modbus RTU,CAN2.0 |
| Certification Standards | |
| Safety certification | IEC62619/IEC63056/IEC62477 |
| EMC certification | CE |
| Grid Connection Standard | EN 50549-1/10 |
