High Power Output: N-type MBB half cut technology, improve energy density, bring higher power output. High Bifacial Factor, up to 25% extra power generation
High Durability: Passed TUV Salt & Ammonia corrosion test, and 2400Pa wind load, 5400Pa snow load test, higher reliability
Better Low Light Performance:Higher power generation compare with standard module in cloudy, foggy and low light condition
Low Power Degradation: First year power degradation <1.0%，year 2-30 power degradation <0.40% each year
Low Temperature coefcient:Passivated contact cell technology for higher power generation in operating
Better Anti-LID:O-type cells with boron-oxide-free composite LID to increase module power generation
Product Parameters
Electrical Data (STC)
| Maximum Power (Pmax/W) | 580 | 585 | 590 | 595 | 600 |
| Open Circuit Voltage (Voc/V) | 52.19 | 52.34 | 52.49 | 52.64 | 52.79 |
| Short Circuit Current (Isc/A) | 13.89 | 13.97 | 14.05 | 14.13 | 14.21 |
| Voltage at Maximum Power (Vmp/V) | 43.91 | 44.06 | 44.21 | 44.36 | 44.51 |
| Current at Maximum Power (Imp/A) | 13.21 | 13.28 | 13.35 | 13.42 | 13.49 |
| Module Efficiency (%) | 22.45 | 22.65 | 22.84 | 23.03 | 23.23 |
| Operating Temperature | -40° C~+85° C | ||||
| Maximum System Voltage | 1000/1500V | ||||
| STC (Standard Testing Conditions): lrradiance 1000W/m2, Cell Temperature 25℃ , AM1.5 | |||||
Electrical Data (NMOT)
| Maximum Power (Pmax/W) | 437 | 441 | 445 | 449 | 453 |
| Open Circuit Voltage (Voc/V) | 49.59 | 49.72 | 49.81 | 49.9 | 49.99 |
| Short Circuit Current (Isc/A) | 11.37 | 11.45 | 11.53 | 11.61 | 11.69 |
| Voltage at Maximum Power (Vmp/V) | 40.84 | 40.92 | 41.01 | 41.1 | 41.19 |
| Current at Maximum Power (Imp/A) | 10.71 | 10.78 | 10.86 | 10.93 | 11.00 |
| NMOT (Nominal Moudule Operating Temperature): lrradiance 800W/m2, Ambient Temperature 20℃ , AM1.5, Wind Speed 1m/s | |||||
Bifacial Power Generation Parameters (Backside Gains)
| 5% | Maximum Power (Pmax/W) | 609 | 614 | 620 | 625 | 630 |
| Module Efficiency (%) | 23.57 | 23.78 | 23.98 | 24.18 | 24.39 | |
| 15% | Maximum Power (Pmax/W) | 667 | 673 | 679 | 684 | 690 |
| Module Efficiency (%) | 25.82 | 26.04 | 26.27 | 26.49 | 26.71 | |
| 25% | Maximum Power (Pmax/W) | 725 | 731 | 738 | 744 | 750 |
| Module Efficiency (%) | 28.07 | 28.31 | 28.55 | 28.79 | 29.03 |
Mechanical Data
| Cell Type | 182×91mm Mono |
| Cell Orientation | 144(6×24) |
| Module Dimensions | 2278×1134×30mm |
| Weight | 32.0kg |
| Front Glass | 2.0mm high transmittance, reinforced glass |
| Rear Glass | 2.0mm part of the structure is grid-like white ceramic glass |
| Frame Material | Anodized aluminum alloy |
| Junction Box | Protection class IP68 |
| Cable | 4.0 mm2 positive pole: 200 mm negative pole: 250 mm wire length can be customized |
Temperature Coefficients
| Temperature Coefficient (Pm) | -0.290%/℃ |
| Temperature Coefficient (Voc) | -0.250%/℃ |
| Temperature Coefficient (Isc) | 0.045%/℃ |
| NMOT (Nominal Moudule Operating Temperature) | 41±3℃ |
Packaging
| Transportation methodspallet | Number of modules per cabinet | Number of modules per |
| 40HQ container | 740 pcs | 37 pcs +37 pcs |
