Meets the splicing, optical splitting, wiring and protection connections of 1~2 Φ8~15 optical cables and 12 wiring pigtails (or leather cables) terminals;
Maximum capacity: 12 cores;
Protection level: IP55;
Adapter/pigtail: 12-core fiber optic adapter can be installed; SC and FC adapters are optional;
Optical splitter: meets box-type optical splitter 1:4, 1:8;
Installation method: pole, wall-mounted;
Product Parameters
| Product model | model | Product size | weight | Material | Cable entry hole |
| HJ-GF-KJW-12A | HJ-GF-KJW-12A | 280*300*80mm | 2.0~2.8kg | Galvanized sheet 0.8~1.2mm | 1 in 2 out |
| HJ-GF-KJW-12B | HJ-GF-KJW-12B | 300*200*100mm | 1.8~2.4kg | Galvanized sheet 0.8~1.2mm | 1 in 2 out |
| HJ-GF-KJW-24A | HJ-GF-KJW-24A | 420*380*90mm | 2.4~3.8kg | Galvanized sheet 1.0~1.2mm | 3 in and 1 out |
| HJ-GF-KJW-96A | HJ-GF-KJW-96A | 600*400*200mm | 4.9~6.9kg | Galvanized sheet 1.0~1.2mm | 2 into 12 holes |
| HJ-GF-KJW-96B | HJ-GF-KJW-96B | 650*480*160mm | 4.2~5.9kg | Galvanized sheet 1.0~1.2mm | 2 into 12 holes |
| HJ-GF-KJW-48B | HJ-GF-KJW-48B | 500*650*200mm | 4.8~5.8kg | Galvanized sheet 1.0~1.2mm | 15 holes |
| HJ-GF-KJW-48A | HJ-GF-KJW-48A | 500*420*150mm | 2.8~4.2kg | Galvanized sheet 1.0~1.2mm | 3 in 2 out |
