Integrated Design: The system integrates the camera, AI video analysis terminal, lighting system, lifting system, transmission and storage system, energy storage power supply system, trailer body, control system, and more;
Modular Structure Design: The camera, lighting, lifting mechanism, battery box, and storage host adopt a modular structure design;
Pneumatic Lifting Pole: Pneumatic lifting pole, with a height of 10 meters when fully raised; consists of 7 sections, with 6 sections raised; retracted height of 2.1 meters, maximum outer diameter of 210mm, minimum inner diameter of 65mm, made of aluminum alloy; T6 treated, wind resistance rating of 8;
Supports Dual TF Card Storage: Supports dual TF card storage, with a maximum of 256GB per card, enabling up to 40 days of recording (expandable with hard disk storage, supporting larger hard drive capacities);
Intelligent Detection: Supports the extension of license plate recognition and facial recognition, or facial recognition, helmet detection, smoking detection, reflection detection, and mask detection, regardless of network availability; on-site alerts for non-compliant behavior, real-time snapshots and video recording on the remote platform with alarm notifications;
Product Parameters
| Mobile Military Station Evidence Collection System | |
| Model | HJ-PRO8-AI-LED |
| Camera Parameters | |
| Resolution | 20x HD PTZ Camera 1920×1080P |
| Frame Rate | 25/30 fps |
| Audio/Video Compression | H.264/H.265 |
| Horizontal/Vertical Angle | Horizontal 360°, Vertical +0° ~ -90° |
| Resolution | 1920×1080P |
| Focal Length | F=4.7-87mm (customizable) |
| AI Smart Analysis | |
| AI Smart Analysis | License plate recognition, facial recognition, helmet detection, smoking detection, reflection detection, mask detection, etc. |
| Platform Integration | Ok Dynamic Evidence Collection Platform, Mobile AI Management Platform, supports GB28181 |
| LED Parameters | |
| Note | 2*120W |
| Lighting Range | 120 meters |
| Beam Angle | 25° |
| Lumens | 24000lm |
| Pan/Tilt | Supports full 320° horizontal and 360° vertical rotation |
| Operating Temperature Range | -40°C to 50°C |
| Recorder Parameters | |
| Alarm Output | 2 switch outputs, linked with sound-light alarm, power failure, etc. |
| Wireless Transmission | Wireless bridge technology or 5G/4G transmission |
| Positioning | Supports built-in GPS/BD module, reports to the department’s platform |
| Storage | Supports up to 4TB hard drive storage |
| Trailer Parameters | |
| Standby Time | Uses 48V200AH battery, single battery lasts over 50 hours (customizable based on requirements) |
| Charging Method | Grid power, solar power, vehicle charging input (wind power can be added) |
| Solar Power | 8*200W |
| Lifting Pole Height | 3.5 meters to 10 meters (customizable) |
| Wind Resistance | Works in up to 8-level winds, no damage in 12-level winds |
| Trailer Structure | Tow arm |
| Trailer and Support | 5-point support |
| Tires and Rims | R13/165 or R14/185 or higher |
| Shock Absorption | Steel plate shock absorption |
| Brakes | Impact brake/hand brake |
| Shock Absorption | Steel plate shock absorption |
| Tow Style | Ring or ball type |
| Low-Temperature Operation | -25°C |
| High-Temperature Operation | 65°C |
| Humidity | Less than 90% (at 25°C) |
| Rainfall | Intensity 6mm/min, duration 1h |
| Safety | Self-locking at any height, no sudden descent |
