Flexible Configuration: Adopting the 1P260S configuration, the number and arrangement of cells can be flexibly adjusted based on actual needs to meet the energy and power requirements of different projects.
High Power Factor: The power factor range is from 1 (leading) to 1 (lagging), which effectively improves energy utilization, reduces line losses, and optimizes grid operation quality.
Reliable Off-grid Operating Parameters: The independent inverter’s rated output voltage is 400V (340~460V), with a voltage imbalance of less than 2%, and short-term imbalance not exceeding 4%, ensuring stability and reliability during off-grid operation.
Comprehensive Protection Features: Equipped with various protection functions, including high/low voltage ride-through, anti-islanding, AC overcurrent, AC short circuit, AC overvoltage/undervoltage, and AC input line phase sequence errors, effectively ensuring the safe operation of the system and equipment.
High Efficiency: The maximum efficiency can reach 99%, minimizing energy loss and improving energy utilization efficiency.
Product Parameters
| Technical Specifications | HJ-G65-261L/HJB-G65-261L | HJ-G130-261L/HJB-G130-261L | |
| DC Side Parameters | |||
| Cell Type | LFP 3.2V/314Ah; SSB 3.2V/314Ah | ||
| Configuration | 1P260S | ||
| Rated Energy | 261kWh | ||
| Voltage Range | 650~949V | ||
| Cycle Life | >8000 cycles @70%EOL, 25°C | ||
| Communication Interface | RS485, CAN, Ethernet | ||
| Compliance Standards | GB/T36276, GB/T34131 | ||
| AC Side Parameters | |||
| Rated Output Power | 65kW | 130kW | |
| Rated Grid Voltage | 400V, Three-phase, Five-wire | ||
| Allowed Grid Voltage Range | 340~460V, ±15% | ||
| Rated Current | 93A | 187A | |
| Power Factor | 1 (Leading) ～ 1 (Lagging) | ||
| Rated Grid Frequency | 50 ±5Hz | ||
| Overload Capacity | 110%: Continuous Operation; 120%: Not less than 1 minute | ||
| Total Current Harmonic Distortion (THDi) | <1.5%(100%PN) <5%(≥20%PN) | ||
| Off-grid Operating Parameters | |||
| Independent Inverter Rated Output Voltage | 400V (340~460V) | ||
| Independent Inverter Voltage Imbalance | <2%, Short-term up to 4% | ||
| DC Side Parameters | |||
| DC Operating Voltage Range | 650V~1000V | ||
| Full Power Operating Range | 650V~950V | ||
| Maximum DC Current | 110A | 220A | |
| Basic Parameters | |||
| Protection Functions | High/Low Voltage Ride-Through, Anti-Islanding, AC Overcurrent, AC Short Circuit, AC Overvoltage/Undervoltage, AC Line Phase Sequence Error | ||
| Maximum Efficiency | 99.00% | ||
| Protection Rating | IP20 | ||
| Operating Temperature | 30°C ~ 70°C (>50°C Derating) | ||
| Relative Humidity | 0~95% (Non-condensing) | ||
| Cooling Method | Air Cooling | ||
| Dimensions (L*W*H) | 715mm * 500mm * 190mm | ||
| Weight | ≤66kg ± 0.5kg | ||
| Noise Index | <80dB | ||
| Maximum Operating Altitude | 3000m (>3000m Derating) | ||
| Communication Method | RS485, CAN, Ethernet | ||
| Compliance Standards | GB/T34120, GB/T34133, EMC | ||
| System Parameters | |||
| Dimensions (H*D*W) | 2438mm * 970mm * 1300mm | ||
| Weight | ≈2.8T | ||
| Protection Rating | IP54 (Electrical Parts), IP66 (Battery Parts) | ||
| Corrosion Resistance Rating | C4/C5 | ||
| Cooling Method | Liquid Cooling | ||
| Operating Temperature Range | -30°C ~ 50°C (>45°C Derating) | ||
| Operating Humidity Range | 0~95% (Non-condensing) | ||
| Maximum Operating Altitude | 3000m (>2000m Derating) | ||
| Fire Protection Method | Aerosol + PACK-Level Immersion + Active Warning | ||
| External Communication Protocol | Modbus RTU, CAN2.0, Modbus TCP | ||
