Integrated Design: Core components such as the battery, PCS, EMS, and fire protection system are integrated into a single container, simplifying installation and maintenance processes;
High Safety: Equipped with a comprehensive fire protection system, including a pipe network fire cabinet, fire control cabinet, fire host, fire cylinders, etc., ensuring the safety of the system during operation;
Intelligent Control System: Utilizes an EMS energy management system to optimize energy distribution and management, improving system efficiency and reliability. Strong environmental adaptability;
Flexible Configuration Options: Can be configured for off-grid or grid-connected modes to meet the needs of various application scenarios;
Product Parameters
| Model | HJ-G1000-2890F |
| Cell Type | LFP 3.2V / 314Ah |
| Energy Rating | 2.89 MWh |
| Combined Configurations | 12P240S |
| Voltage Range | DC 672V–864V |
| Dimensions (L × W × H) | 12192 × 2438 × 2896 mm |
| Weight | ≈35 T |
| Ingress Protection Grade | IP54 |
| Fire Fighting Metdods | Container-level fire fighting system, including a gas detection device, fire alarm system, and FK-5-1-12 fire suppression system witd a pipe network. |
| Maximum Operating Altitude | 3000 m (>2000 m derating) |
| Operating Temperature Range | -30°C to 55°C (>45°C derating) |
| Cooling Metdod | Air Cooling |
| Communication Protocol | Modbus TCP/RTU, IEC 60870-5-104, CAN |
| Rated Output Power | 1000 kW |
| Rated Output Current | 1440 A |
| Total Harmonic Current Distortion (THDi) | <3% |
| Rated Grid Frequency | 50/60 Hz |
| Product Standards | IEC 62477-1, IEC 62619, IEC 63056, EU 2023/1542 |
| Safety Certifications | UN38.3, MSDS |
| EMC Certifications | EN IEC 61000-6-1/2/3/4 |
| Grid Connection Standards | EN 50549-1, EN 50549-2 |
