High-Performance Cells: Uses LFP-314Ah cells, offering excellent safety and long lifespan;
Large Capacity and High Power: Nominal capacity of 241.15kWh/1P224S and rated power of 120KW, capable of providing efficient charge and discharge capabilities in a short time to meet various power demands;
Wide Voltage Range: Voltage range between 672~864V, adaptable to different electrical devices and system requirements, enhancing compatibility and applicability;
Efficient Heat Dissipation: Uses air cooling to ensure the equipment maintains a good operating temperature during high-load operation, extending its lifespan and improving operational efficiency;
Strong Adaptability: Operating temperature range from -25°C to 60°C, capable of functioning normally under various harsh environmental conditions, without condensation, and offering a broad range of applications;
High Safety Performance: Equipped with a fire protection system consisting of FM-200 + Aerosol + Active Pre-Warning, effectively enhancing equipment safety and reducing fire risks.
Product Parameters
| Model | HJ-G0110-0241F |
| Cell Type | LFP-314Ah |
| Nominal Capacity | 241.15kWh/1P224S |
| Charge/discharge ratio | <0.5C |
| Nominal Voltage | 768V |
| Voltage range | 672~864V |
| Maximum Charge/Discharge Current | 157A |
| Rated Power | 120kW |
| Grid-connected voltage | 400V |
| Power factor | -1~1 |
| Rated Grid Frequency | 50Hz |
| System efficiency | ≥89% |
| Charge/discharge depth | 100%DOD |
| Working Temperature | -25~60°(Derated above 45°) |
| Humidity | ≤ 9 5 % None Condensing |
| Cooling method | Air-cooled |
| IP Rating | IP54 |
| Communication mode | Ethernet/RS485 |
| Altitude | 3 0 0 0 m (Derated above 3 0 0 0 m) |
| Dimension(W*D*H) | 1400*1300*2387mm |
| Fire Fighting System | Perfluorohexanone + Aerosol + Active Pre-Alarm |
| Weight | 3000kg |
