Efficient Energy Storage: Lithium iron phosphate battery, with a rated capacity of 5MWh, capable of storing a large amount of energy to meet long-term energy storage needs;
Low Self-Discharge: Self-discharge rate ≤3% per month, ensuring minimal energy loss even during long periods of idle time, maintaining the availability of the stored energy;
Low Noise Operation: Noise level < 65dB at 1 meter from the system, with minimal impact on surrounding environmental noise, making it suitable for noise-sensitive applications;
Product Parameters
| Model | HJ-G2500-5000F |
| Cell Type | LFP 3.2V / 314Ah |
| Energy Rating | 5 MWh |
| Combined Configurations | 12P416S |
| Voltage Range | DC 1164.8V–1497.6V |
| Dimensions (L × W × H) | 12192 × 2438 × 2896 mm |
| Weight | ≈55 T |
| Ingress Protection Grade | IP54 |
| Fire Fighting Metdods | Container-level fire fighting system, including a gas detection device, fire alarm system, and FK-5-1-12 fire suppression system witd a pipe network. |
| Maximum Operating Altitude | 3000 m (>2000 m derating) |
| Operating Temperature Range | -30°C to 55°C (>45°C derating) |
| Cooling Metdod | Air Cooling |
| Communication Protocol | Modbus TCP/RTU, IEC 60870-5-104, CAN |
| Rated Output Power | 2500 kW |
| Rated Output Current | 2300 A |
| Total Harmonic Current Distortion (THDi) | <3% |
| Rated Grid Frequency | 50/60 Hz |
| Product Standards | IEC 62477-1, IEC 62619, IEC 63056, EU 2023/1542 |
| Safety Certifications | UN38.3, MSDS |
| EMC Certifications | EN IEC 61000-6-1/2/3/4 |
| Grid Connection Standards | EN 50549-1, EN 50549-2 |
