Simple Installation Design
Easy Moving with Wheels design
Superior BMS with Brand Battery Cell
Large capacity range :15kWh-105kWh
Wide Compatibility
Product Parameters
| MODEL | HJ-HBL48101S（B-61） | HJ-HBL48101S（B-62） |
|---|---|---|
| Cell type | LiFePO4 | LiFePO4 |
| Rated Voltage(V) | 384 | |
| Rated Capacity(Ah) | 100 | |
| Rated Energy(kWh) | 15.36 | |
| Voltage Range(V) | 134.4～172.8 | |
| Max.Charging Current(A) | 100 | |
| Recommended Charging Current(A) | 50 | |
| Max.Discharging Current(A) | 100 | |
| Efficiency | 0.98 | |
| Dimension H*W*D(mm) | 660*557*454 | |
| Carton Dimension,H*W*D(mm) | 720*510*221（for a single pack of battery box）714*507*376（for high-voltage box + base） | |
| Net Weight(kg) | 160 | |
| Gross Weight(kg) | 173 | |
| Humidity | Indoor (5%-95%(RH) No Condensing) | waterproof（5%~95%） |
| Charging Temperature | 0℃~55℃(32 °F~131 °F) | |
| Discharging Temperature | -20℃~55℃(-4 °F～131 °F) | |
| Storage Temperature | -20℃~55℃ (-4 °F~131 °F) | |
| Cycle Life | ≥6000@25℃ | |
| Design Life | 15+ Years (25°C/77 ℉) | |
