High Energy Density Reduces Product Weight and Footprint, Featuring a Stackable Design
Outstanding High Current Charge/Discharge Performance
Ultra-Long Cycle Life Reduces Maintenance Costs
Multiple Protection Features: Overcharge Protection, Low Discharge Voltage Protection, Overcurrent Protection during Charge/Discharge, High-Temperature Protection, Short-Circuit Protection, Reverse Polarity Protection, Surge Protection, and Electrostatic Discharge Protection
Automatic Configuration when Paralleled, No Manual Operation Required, Supports up to 15 Units in Parallel
Product Parameters
| Product Model | HJ-HBL48101S (B-21) |
| Battery Cells | LiFePO4 3.2V/100Ah |
| Array Configuration | 16S1P |
| Rated Capacity | 100Ah |
| Minimum Capacity | ≥96Ah |
| Capacity | 5.12kWh |
| Operating Voltage | 40 – 58.4V |
| Rated Voltage | 51.2V |
| Internal Resistance | IR ≤ 0.5mΩ |
| Charging Voltage | 58.4V |
| Discharge Cutoff Voltage | 40V |
| Standard Charging Current | 50A |
| Standard Discharging Current | 50A |
| Max Continuous Discharge Current | 100A |
| Communication Port | RS485/CAN |
| Indicator Lights | ALM / RUN / SOC |
| Cycle Life | 6000 cycles @ 70% SOH |
| Operating Temperature | Charging: 0℃～60℃; Discharging: -20℃～60℃ |
| Storage Temperature | 1 month: -20℃～45℃; 1 year: 0℃～35℃ |
| Net Weight | 42.5Kg |
| Net Dimensions (W×H×D) | 550×370×140 (mm) |
