Efficient: 30 inputs,{>} 150% DC/AC ratio;
Each MPPT maximum current 80A, compatible with 182 and 210 series bifacial modules;
Patented heat transfer technology, continuous output increase of 5% at high temperature;
Safe: IP66, C5-M Anti-Corrosion level;
Intelligent string break, remote release for DC switch，active safety;
Support intelligent AC/DC terminal temperature detection;
Smart:Intelligent string monitoring, smart l-V curve scan;
Each MPPT online insulation fault detection facilitates rapid fault identification;
Low temperature antifreeze,reverse dust removal indoor dehumidification;
Economic:Inverter with 20ms fast reactive power response, can replace SVGt;
Support 400mm’aluminum wire connection, savingAC cable costt;
Support PLC communication,saving communication cables and construction cost;
Product Parameters
| Production Model | HJ-IG48803T(E-33) |
| PV Input Date | |
| Max, Input Power | 120KW |
| MPPT Operating Voltage Range | 180-1000V |
| Max.Short Circuit Current | 40A |
| Number of MPPT Trackers | 6 |
| AC Data | |
| Nominal Power | 80kW |
| Nominal Voltage | 230V/400V，3L / N / PE |
| Nominal Frequency | 50Hz / 60Hz |
| Max.Current | 133.4A |
| Power Factor | >0.99 ( 0.8 leading ~ 0.8 lagging ) |
| Protection | |
| Protection | DC Reverse Polarity Protection Anti-islanding Protection AC Short Circuit Protection Residual Curent Monitoring Unit Insulation Resistance Monitoring Ground Fault Monitoring Grid Monitoring Py String Monitoring Surge Protection |
| General Data | |
| Operating Temperature Range | -30° C ~ +60° C |
| Cooling | Smart Cooling |
| Relative Humidity | 0 ~ 100% |
| Display | LCD/LED+APP |
| Communication | RS485/WiFi / GPRS / Ethernet |
| Installation | wall-mounted |
| Protection Degree | IP66 |
| Dimension (W*D*H) | 780x585x333mm |
| Weight | 77.8Kg |
| Certification | |
| Production Certification | IEC 62109-1, IEC 62109-2, IEC 61000-6-2, IEC 61000-6-4，EN 62920，IEC 61727, IEC 62116, IEC 60068, IEC 61683 |
