Simple installation supporting wall-mount, pole-mount, and floor-standing configurations
Internal space reserved for fiber splice tray and passive WDM installation, facilitating fiber access
Built-in lithium battery provides reliable backup power
Intelligent power-down function with remote control over individual branch circuit switching
Product Parameters
| Model | HJDUM01-048(5000W) | HJDUM01-048(900W) |
| Capacity | 5000W | 9000W |
| Module Specifications | Full config: 2×48V/50A modules | Full config: 3×48V/50A modules |
| Dimensions | 520(H)*390(W)*250(D)mm | 570(H)*500(W)*330(D)mm |
| AC Input | 63A/2P*1 | 63A/2P (with residual current protection) ×1 |
| Lightning Protection Device | AC lightning protection + DC lightning protection | |
| DC Output | MCB 63A×3; MCB 32A×6 | MCB 63A×6; MCB 32A×6; |
| Battery Interface | 1× internal + 1× external battery interface | |
| Communication Method | Wireless NB-IoT or 4G | |
| Lithium Battery | Includes 1×100Ah lithium battery | |
| Fiber Transmission | Fiber splice tray + passive WDM slot | |
| Protection Rating | IP55 | |
