Multi-Energy Complementarity — Smoothing Power Fluctuations
Intelligent generator start-up keeps the diesel generator in its efficient operating range, reducing idle fuel consumption
Economic Benefits: Lower Fuel Consumption, Reduced O&M, Extended Lifespan
Engineered for Harsh Environments,−40°C to +55°C; high humidity, high salt-fog, high altitude, and dusty conditions
Product Parameters
| Base Station Energy System Specifications | |||
| Product Model | HJ-CHI-18030-W | HJ-CHI-36040-W | |
| Cabinet Parameters | Dimensions | 1600mm*600mm*600mm | 2200mm*700mm*700mm |
| Application Scenario | Indoor Floor-Standing | Indoor Floor-Standing | |
| Weight | ≤95 kg (excluding battery) | ≤145 kg (excluding battery) | |
| Input Characteristics | AC Input | AC 380V/220V, 50Hz; MCB 63A/4P; SPD ×1; Output 16A ×1 (optional) | AC 380V/220V, 50Hz; MCB 63A/4P; SPD ×1; Output 16A ×1 (optional) |
| PV/Wind Input | Supported, optional | Supported, optional | |
| Max. Power Supply | Capacity | 18KW(300A) | 36KW(600A) |
| Efficiency | 93% (96% optional) | 93% (96% optional) | |
| Rectifier | Single Module Spec | 48V/50A module, 75A optional | 48V/50A module, 75A optional |
| Total Capacity | Max. 18 kW (300A) | Max. 36 kW (600A) | |
| Note: Combined rectifier + PV capacity is 300A; when rectifiers are fully populated, no PV capacity is available | Note: Combined rectifier + PV capacity is 300A; when rectifiers are fully populated, no PV capacity is available | ||
| PV Controller (MPPT) | Single Module Spec | 48V/50A module, 75A optional | 48V, 50A or 75A optional |
| MPPT Input Voltage | 60~150V, optional (200V~400V) | 60~150V, optional (200V~400V) | |
| Total Capacity | Max. 18 kW (300A) | Max. 36 kW (600A) | |
| PV Modules | Max. PV Power (W) | Recommended 9 kW (3~18 kW optional) | Recommended 18 kW (3~36 kW optional) |
| Battery Parameters | Battery Rated Voltage (V) | 48V(40~60V) | 48V(40~60V) |
| Max. Charge/Discharge Current (A) | 90A (C-rate 0.3C) | 180A (C-rate 0.3C) | |
| Capacity | 30KWh | 40KWh | |
| Output Characteristics | Bypass AC Output | 220/230Vac（380/400Vac) | 220/230Vac（380/400Vac) |
| DC 48V Output Voltage | 43.2V DC ~ 58V DC (default 53.5V DC) | 43.2V DC ~ 58V DC (default 53.5V DC) | |
| Rated Output Power | Max. 18 kW (300A) | Max. 36 kW (600A) | |
| Peak Efficiency | 96% | 96% | |
| DC Output Interface | MCB: 125A×2, 63A×2, 32A×2, 16A×2 (configurable per customer) | MCB: 125A×2, 63A×2, 32A×2, 16A×2 (configurable per customer) | |
| Application Scenario | / | Grid-tied / Off-grid (optional) | Grid-tied / Off-grid (optional) |
