Integrated Regulator: Integrated photovoltaic and energy storage system modem, supports multiple batteries, and is integrated with the EMS intelligent energy management system;
Intelligent Switching: UPS function, supports three-phase imbalance, grid connection/disconnection within 10ms;
Wide Voltage Input Range: Wide photovoltaic voltage input range of 180V-900V. Wide battery voltage range of 180V-700V;
Safe and Reliable: IP65 protection level, aluminum casing, built-in lightning protection, high-precision leakage protection;
Intelligent and Simple: Ultra-quiet, flexible communication, supports remote/local USB upgrades;
Product Parameters
| Category | Parameter | HJ-IH10-W500T (H-4) | HJ-IH12-W500T (H-5) |
| Photovoltaic Input | Max DC Input Power (kW) | 15 | 18 |
| Rated DC Voltage (V) | 1000 | ||
| Max DC Input Voltage (V) | 620 | ||
| DC Input Voltage Range (V) | 150 – 1000 | ||
| MPPT Voltage Range (V) | 150 – 850 | ||
| Full MPPT Voltage Range (V) | 500 – 850 | ||
| Startup Voltage (V) | 160 | ||
| Max DC Input Current (A) | 18.5×2 | ||
| Max Short Circuit Current (A) | 25×2 | ||
| MPPT Trackers/Strings | 2/2 | ||
| Battery Interface | Battery Rated Voltage (V) | 350 | 450 |
| Battery Voltage Range (V) | 80 – 600 | ||
| Max Charge/Discharge Current (A) | 30 | ||
| Max Charge/Discharge Power (kW) | 10 | 12 | |
| Charging Curve | 3 Stages | ||
| Compatible Battery Types | Li-ion / Lead-acid / Sodium Metal Chloride Battery | ||
| AC Grid | Rated AC Output Power (kW) | 10 | 12 |
| Max AC Output Power (kVA) | 45.976 | 18 / 13.2 | |
| Max AC Output Current (A) | 17 | 21.5 | |
| Rated AC Voltage (V) | 3P+N+PE: 3P+PE 230/400 | ||
| Rated AC Frequency (Hz) | 50/60 | ||
| Power Factor | 1 (-0.8 – 0.8 adjustable) | ||
| Total Harmonic Distortion (THD) (%) | <3% | ||
| AC Load Output (Backup) | Rated Output Power (kW) | 10 | 12 |
| Rated Output Voltage (V) | 3P+N+PE: 3P+PE 230/400 | ||
| Rated Output Frequency (Hz) | 50/60 | ||
| Rated Output Current (A) | 14.5 | 17.4 | |
| Peak Output Power | 11kVA, 60s | 13.2kVA, 60s | |
| Total Harmonic Distortion (Linear Load) | <3% | ||
| Switching Time (ms) | <10 | ||
| Efficiency | European Efficiency | 97.50% | |
| Max Efficiency | 98.20% | 98.30% | |
| Battery Charge/Discharge Efficiency | 98.00% | ||
| Protection | Reverse Polarity Protection | Yes | |
| Reverse AC Polarity Protection | Yes | ||
| Overcurrent/Overvoltage Protection | Yes | ||
| Anti-Islanding Protection | Yes | ||
| AC Short Circuit Protection | Yes | ||
| Leakage Current Detection | Yes | ||
| Ground Fault Monitoring | Yes | ||
| Grid Monitoring | Yes | ||
| Enclosure Protection Rating | IP65 | ||
| AC/DC Surge Protection | Type II | ||
| General Parameters | Dimensions (W×D×H, mm) | 370 × 585.5 × 193mm | |
| Weight (kg) | 22kg | ||
| Topology | Transformerless | ||
| Cooling Concept | Intelligent Fan | ||
| Relative Humidity | 0 – 100% | ||
| Operating Temperature Range (°C) | -25 – 60°C | ||
| Operating Altitude (m) | <4000 | ||
| Standby Power Consumption (W) | <5 | ||
| Display & Communication Interfaces | LCD, LED, RS485, CAN, WIFI, GPRS, 4G, SunSpec | ||
| Certifications & Approvals | NRS097, G98/G99, EN50549-1, C10/11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2, IEC62477-1 | ||
| Electromagnetic Compatibility (EMC) | EN61000-6-2, EN61000-6-3 | ||
