Full outdoor protection for harsh environments: high Protection Rating — IP54/IP55/IP65 optional — rainproof, dustproof, and UV-resistant
High-safety design: BMS protection against overcharge, over-discharge, overcurrent, over-temperature, short circuit, and cell balancing
Intelligent management and remote monitoring: supports 4G/Ethernet remote monitoring for real-time viewing of voltage, current, SOC, SOH, temperature, and alarms
High-reliability backup power and cycle performance: LFP (Lithium Iron Phosphate) cells with cycle life ≥6,000 cycles
Product Parameters
| Base Station Battery Cabinet Specifications | |||||
| Product Model | HJ-CBI-030W | HJ-CBI-050-W | HJ-CBO-030-W | HJ-CBO-050-W | |
| Cabinet Parameters | Dimensions (H×W×D) | 1600mm*600mm*600mm | 220mm*700mm*700mm | 1600mm*750mm*750mm | 2200mm*800mm*850mm |
| Application Scenario | Indoor Floor-Standing | Indoor Floor-Standing | Outdoor Floor-Standing | Outdoor Floor-Standing | |
| Cable Entry Method | Top/Bottom entry | Top/Bottom entry | Bottom entry | Bottom entry | |
| Thermal Control | / | / | Fan-cooled / Air-conditioned (optional) | Fan-cooled / Air-conditioned (optional) | |
| Weight | ≤65 kg (excluding battery) | ≤125 kg (excluding battery) | ≤160 kg (excluding battery) | ≤200 kg (excluding battery) | |
| Power Input Characteristics | DC Input Voltage | DC 48V(40~60V) | DC 48V(40~60V) | DC 48V(40~60V) | DC 48V(40~60V) |
| Max. Current (A) | 180A | 300A | 180A | 300A | |
| Battery Parameters (Optional) | Rated Voltage (V) | 48V(40~60V) | 48V(40~60V) | 48V(40~60V) | 48V(40~60V) |
| Max. Charge/Discharge Current | 180A (C-rate 0.3C) | 300A (C-rate 0.3C) | 180A (C-rate 0.3C) | 300A (C-rate 0.3C) | |
| Battery Charge Management System | Built-in BMS | Built-in BMS | Built-in BMS | Built-in BMS | |
| Max. Capacity | 30kWh | 50kWh | 30kWh | 50kWh | |
