Design with 1U or 2U height options, perfectly fitting all standard telecommunication and server racks.
Meeting different FTTH deployment needs from small access points to large-scale central office aggregation.
Fiber modes with a wide operating wavelength range (1260-1650nm) for high compatibility.
High-quality metal housing made of cold-rolled steel provides robust structural integrity and superior mechanical protection for internal PLC splitter chips.
Product Parameters
| Item | Value |
| Product Name | 1U 19″ Rack Mount PLC Fiber Optic Splitter |
| Model Number | Rack-mount |
| Product Type | Rack-mount PLC Fiber Optic Splitter |
| Standard | 19 Inch Rack Mounted |
| Height | 1U / 2U (Optional) |
| Configuration | 1×4 / 1×8 / 1×16 / 1×32 / 1×64 |
| Fiber Mode | Single Mode (SM) / Multi Mode (MM) |
| Wavelength | 1260 nm to 1650 nm |
| Insertion Loss | ≤ 16.8 dB (based on 1×64) |
| Connector Type | SC, FC (UPC or APC optional) |
| Color | White / Black |
| Material | Cold Rolled Steel (Metal Housing) |
| Application | FTTH Solution; Telecommunication Networks; PON Systems; Data Center |
