Independent MPPT: One microinverter connects two modules with independent MPPTs.
High Power: Maximum output power reaches 2000W.
High Protection Level: IP67 high protection level.
Comprehensive Features: Built-in Wi-Fi and Bluetooth; built-in safety protection relay; direct wall socket plug-in.
Product Parameters
| DC Input | |
| Recommended Module Power Range | 315Wp-660Wp+ |
| MPPT Voltage Range | 56V-90V |
| Operating Voltage Range | 52V-118V |
| Maximum DC Input Voltage | 118V |
| Maximum DC Input Current | 20A x 2 |
| Maximum DC Short-Circuit Current | 25A x 2 |
| AC Output | |
| Rated Output Power | 1900W |
| Maximum Output Power | 2000W |
| Rated Output Voltage / Default Output Voltage Range | 220V / 187V-242V |
| Maximum Output Current | 8.6A |
| Rated Output Frequency / Default Output Frequency Range | 50Hz / 47.5Hz-50.5Hz |
| Power Factor | >0.99 |
| Efficiency | |
| Maximum Efficiency | 97% |
| MPPT Tracking Efficiency | 99.50% |
| Night Loss | 20mW |
| Mechanical Data | |
| Operating Temperature | -40℃ to +65℃ |
| Storage Temperature | -40℃ to +85℃ |
| Dimensions (LxWxH) | 283 mm x 233 mm x 39.5 mm |
| Weight | 4.2kg |
| DC Connector Type | Staubli MC4 PV-ADBP4-S2 & ADSP4-S2 |
| AC Extension Cable | Customer-supplied* |
| Cooling | Natural Cooling (No Fan) |
| Protection Rating | IP67 |
| Pollution Degree | PD3 |
| Working Humidity Range | 4%-100% |
| Maximum Altitude | <2000m |
| Overvoltage Category | PV Input Circuit OVC II, Power Supply Circuit OVC III |
| Features | |
| Communication | Built-in Wi-Fi and Bluetooth |
| Isolation Design | High Frequency Transformer, Current Isolation |
| Energy Management** | AP EasyPower App |
| Warranty | Standard 12 years |
| Compliance | |
| Safety, EMC, and Grid Compliance | NB/T 32004:2018 |
