High Protection Level: IP65 design, high protection level for outdoor installation models.
Strong Compatibility: Compatible with both DC and AC power inputs.
High Efficiency: Optimized MPPT algorithm, achieving efficiency over 99%.
Low Noise: Utilizes natural cooling, ensuring low noise levels.
Intelligent Monitoring: GPRS remote monitoring for real-time operational status, with real-time start/stop control (optional).
Comprehensive Features: Excellent performance with large water output. Fully automatic, unmanned operation with complete protection functions, including overcurrent, overvoltage, output phase loss, short circuit, and overheat protections.
Product Parameters
| Three-phase 380V Output Series 3000W~22kW | |
| Model | HJ-PH0001-W |
| Maximum Allowed String Number | 2~6 |
| Start Voltage (Vdc) | 250 |
| Maximum DC Input Voltage (Vdc) | 900 |
| Recommended MPP Voltage (Vdc) | 450~750 |
| Rated Output Power (W) | 3000~22000 |
| Maximum Output Current (A) | 8~45 |
| Output Frequency (Hz) | 0~50/60 |
| Protection Rating | IP65 |
