Battery Performance: UPS-grade redundant protection to prevent backup load failure;
Storage Performance: Built-in EMS intelligent management system to automatically optimize household energy supply;
Working Environment: Built-in power services, FCAS, VPP, etc.;
Product Parameters
| Product Model | HJ-H10-H05 (k-5) | HJ-H15-H05 (k-6) |
| Battery Type | ||
| Battery Voltage Range [V] | 90-700 | |
| Max Charging Current [V] | 50 | |
| Max Discharging Current [V] | 50 | |
| Input Photovoltaic | ||
| Max Photovoltaic Input Power [kW] | 20 | |
| Max Photovoltaic Input Voltage [V] | 1100 | |
| MPPT Range [V] | 140-950 | |
| Startup Voltage [V] | 120 | |
| Max Input Current [A] | 16/16/16 | |
| Max Short Circuit Current [A] | 24/24/24 | |
| MPPT Trackers | 3 | |
| Number of Strings per MPPT Tracker | 1/1/1 | |
| Grid Port | ||
| Rated Output Power [kVA] | 10 | |
| Max Output Current [A] | 16.7 | |
| Max Apparent Output Power [kVA] | 10 | |
| Max Input Power [kVA] | 20 | |
| Rated Grid Voltage [Vac] | 220/380, 230/400, 3/N/PE | |
| Grid Voltage Range [Vac] | 180-270 | |
| Rated Grid Frequency [Hz] | 50/60 | |
| Power Factor | -0.8~+0.8 | |
| THDi | <3% | |
| Backup Port | ||
| Surge Backup Power [kVA] | 20 | |
| Rated Backup Power [kVA] | 10 | |
| Rated Backup Voltage [Vac] | 220/380, 230/400, 3/N/PE | |
| Rated Backup Frequency [Hz] | 50/60 | |
| THDv | <3% (Linear Load)/ <5% (Non-linear Load) | |
| DCV | <100mA | |
| Peak Ratio | 3:1 | |
| Switching Time [ms] | <10 | |
| Efficiency | ||
| Max Efficiency [Hz] | 98.40% | |
| European Efficiency [Hz] | 97.90% | |
| MPPT Efficiency [Hz] | 99.90% | |
| Max Round-trip Efficiency [Hz] | 96.00% | |
| HMI & COMM. | ||
| Communication with BMS | CAN/RS-485 | |
| Load Monitoring | Meter/CT/Backup Box | |
| External Communication | RS-485/WIFI/4G/Ethernet | |
| User Interface | LED/LCD | |
| Battery | ||
| Battery Module | 102.4V 5.3kWh | |
| Battery Type | LFP (LiFePO4) | |
| Number of Modules | 2 | 3 |
| Total Energy [kWh] | 10.6 | 15.9 |
| Rated Voltage [V] | 204.8 | 307.2 |
| Operating Voltage [V] | 160-233.6 | 240-350.4 |
| Max Charging/Discharging Current [A] | 52 | 52 |
| Continuous Discharge Output [kW] | 10 | 15 |
| General Specifications | ||
| Dimensions (W×D×H) [mm] | 740*220*1317 | 740*220*1652 |
| Approx. Weight [KG] | 141 | 191 |
| Protection Rating | IP65 | |
| Operating Temperature [℃] | Charge: 0℃-50℃ / Discharge: 0℃-50℃ | |
| Storage Temperature [℃] | 0℃-35℃ | |
| Humidity | ≤95% | |
| Altitude [m] | ≤3000 | |
| Cycle Life | Inverter: 5 years/10 years; Battery: over 10 years, 6000 cycles (90% depth of discharge, 25℃) | |
| Installation | Stackable, Floor-mounted Installation | |
| Certifications | ||
| Grid Safety Standards | VDE-AR-N4105:2018, G98, G99, C10/11:2021, NTS 631, RD647:2020, UNE 217002:2020, CEI0-21, VDE 0126-1-1, NR | |
| Safety Standards | IEC/EN 62109-1 & 2, IEC/EN 62477-1:2012 | |
| Electromagnetic Compatibility | IEC/EN 61000, IEC/EN 61000-6-2, IEC/EN 61000-6-3, IEC/EN 61000-6-4 | |
| Battery | UN38.3, IEC62619 | |
