High Energy Density: This product utilizes advanced lithium-ion battery technology, significantly reducing weight and footprint, while supporting wall-mounted installation to save space;
Photovoltaic Integration and UPS Function: Supports integration with photovoltaic systems and features UPS (Uninterruptible Power Supply) functionality, automatically switching to ensure continuous power supply for devices;
Extended Cycle Life: The battery supports thousands of charge and discharge cycles, greatly reducing long-term maintenance costs;
Smart Remote Monitoring: Equipped with an RS485 interface, it can connect to Wi-Fi or 4G modules for data transmission and remote monitoring, allowing users to monitor device status anytime and anywhere;
Product Parameters
| Product Model | HJ-H05-O05（B-45） | HJ-H10-O05（B-46） | HJ-H15-O10（B-47） |
| Battery Voltage | 51.2V | 51.2V | 51.2V |
| Battery Capacity | 100Ah | 200Ah | 280Ah |
| Energy | 5.12KWh | 10.24KWh | 14.3KWh |
| Inverter Power | 5KW | 5KW | 11KW |
| MPPT Voltage Range | 120~430Vdc | 120~430Vdc | 90~450Vdc |
| Waterproof Rating | IP20 | IP20 | IP20 |
| Communication Method | RS485/WiFi | RS485/WiFi | RS485/WiFi |
| Dimensions (mm) | 450*270*650mm (approx.) | 450*270*850mm (approx.) | 510*377*770mm |
| Weight (kg) | 51kg (approx.) | 91kg (approx.) | 120kg (approx.) |
