Liquid Cooling Technology: Uses an integrated liquid cooling system with high-efficiency variable frequency compressor and intelligent fan speed control. The cooling capacity and fan speed can be adjusted in real-time according to the thermal load, ensuring the battery operates at an optimal temperature and extending its lifespan;
Energy Management Unit (EMU): Responsible for real-time communication with BMS, PCS, temperature control systems, fire protection systems, and other devices, collecting data and forwarding it to the energy storage cloud platform. Users can view data anytime via web or mobile app. The EMU also serves as a local control unit and can execute various operational strategies, such as peak-valley arbitrage and demand management;
Supports Multiple Access Methods: Supports AC 0.4kV low-voltage side access, allowing for flexible integration into different grid architectures to meet diversified energy access needs;
Multi-functional Integration: Equipped with functions such as peak-valley arbitrage, reverse current protection, and manual grid-connected/off-grid switching. It can adapt to energy management needs in various scenarios, achieving efficient energy utilization and optimal configuration;
Integrated Design: A highly integrated system design with a compact structure, saving space and making it easy to transport and install, allowing for rapid deployment and use;
Product Parameters
| Model | HJ-G100-215L |
| Name | Technical Parameters (Single System) |
| System Parameters | |
| Rated Discharge Power | 100kW |
| Rated Charge Power | 100kW |
| Rated Energy Storage Capacity | 213kWh |
| Energy Storage Battery Type | Lithium Iron Phosphate, 280Ah cells |
| Battery Module Configuration | 1P48S |
| Single Cluster Configuration | 1P240S |
| Maximum Energy Conversion Efficiency | ≥86% |
| DC Side Parameters | |
| Rated Voltage | DC768V |
| Battery Voltage Range | DC 600V~876V |
| Rated Power | 100kW |
| Rated Current | 140A |
| Maximum DC Power | 110kW |
| Maximum DC Current | 192A |
| AC Side Parameters | |
| Rated Grid Voltage / Allowable Grid Voltage Range | 400V (-20% ~ +15%) |
| Rated Grid Frequency / Allowable Grid Frequency Range | 50Hz / 60Hz (±2.5) |
| Rated Power Factor | -0.99 ~ +0.99 |
| Cabinet Parameters | |
| Dimensions (W×D×H) mm | 1300×1300×2275 |
| Weight (t) | ≤3 |
| Installation Method | Cement foundation or channel steel |
| Protection Rating | IP54 |
| Coating Color | RAL 7035 Light Grey, Matte |
| Thermal Management Technology | Liquid Cooling |
