Efficiency
• Advanced MPPT technology with efficiency up to 99.9%
• Maximum 22+22A photovoltaic input current;
Reliability
• Outputs high-quality pure sine wave AC power
• Maximum 72kW load power, meeting the needs of most households;
Safety
• Comprehensive safety protection from hardware to software
• Multiple safety certifications;
User-Friendliness
• Industrial design with a modern aesthetic appearance
• Easy installation and simple operation;
Integration
• Supports up to 260A charging current
• Supports lithium-ion battery BMS communication;
Intelligence
• Exclusive dual activation function for lithium-ion battery BMS
• Time-based functionality to save costs;
Product Parameters
| Product Model | HJ-IO10-W48T（C-2） | HJ-IO12-W48T（C-3） |
|---|---|---|
| PV Input | ||
| Maximum Input Power | 7,500W/7,500W | 9,000W/9,000W |
| MPPT Operating Voltage Range | 200～650Vdc/200～650Vdc | |
| Maximum Input Current | 22A/22A | |
| Number of MPPT Tracks | 2 | |
| Battery Input | ||
| Battery Voltage Range | 40～60Vdc | |
| Maximum Charge/Discharge Current | 120A | 120A |
| Battery Type | Li-ion / Lead-Acid / User Defined (Lithium-ion Battery / Lead-acid Battery / User Defined) | |
| AC Data | ||
| Rated Power | 10,000W | 12,000W |
| Rated Voltage | 230/400Vac, three-phase | |
| Rated Frequency | 50Hz/60Hz | |
| Maximum Current | 22A | |
| Power Factor | 0.8 leading ~0.8 lagging | |
| Protection | ||
| Protection Features | Anti-reverse charge protection, Overcurrent Protection | |
| General Data | ||
| Operating Temperature Range | -10~55℃, >45℃ derated | |
| Cooling | Air Cooling | |
| Relative Humidity | 0~95% | |
| Display | LCD | |
| Communication | RS485 / CAN / USB / Dry contact / Wi-Fi / GPRS | |
| Mounting Method | Wall-mounted | |
| Dimensions (W*D*H) | 620*445*130mm | |
| Weight | 27kg | |
| Certifications | ||
| Product Certification | IEC62109-1/2 | |
